Laboratorium Mini betongblandare

Laboratorium mini betongblandare

Den tektoniska typen av denna maskin har inkluderats i den nationella obligatoriska industrin

(JG244-2009).The performance of this Produkter meets or even exceeds the standards.Due to its scientific design,strict quality control and unique tectonic type,this mixer of double-horizontalshafts features efficient mixing ,well-distributed mixture,and cleaner discharging and it is suitable forInstitutes of scientific resökaes,mixing plant,detection units,as well as laboratory of concrete.

Mixer is mainly composed of retarding mechanism, mixing chamber, worm gear pair, gear, sprocket, chain and bracket, etc.Through the chain transmission, the machine mixing pattern for motor drive axle shaft cone drive, cone by gear and chain wheel drives the stirring shaft rotation, mixing materials.Unloading transmission form for motor through a belt drive reducer, reducer by chain drive stirring the rotate, flip and reset,unloadthe material.

Tekniska parametrar:

1.Tektonisk typ: DubbelhorisonTella axlar

2. Nominal kapacitet: 60L

3. Mixing Motor Power: 3.0kW

4. Dischering Motorkraft: 0,75 kW

5.Material av arbetskammare: Stålrör av hög kvalitet

6. Mixing Blade: 40 Manganese Steel (gjutning)

7. Distans mellan blad och inre kammare: 1mm

8. Tånghet i arbetskammaren: 10mm

9. Bladtankhet: 12mm

10. överAllat dimensioner: 1100 × 900 × 1050mm

11. Vikt: cirka 700 kg

12. Förpackning: träfodral
